32
Overview of Components
Tuning Controller module magnet
Tuning controller module has build in some magnets on both sides that will be
convenient for you to stick it to the chassis. However, we provide extra four magnets
for sticking inside the back cover of module. Please follow the instructions below to
stick the magnets.
1. Loosen the screws of the back cover.
2. Open and turn the back cover over.
3. Remove the sticker from the magnet.
4. Stick four magnets to the designated four locations.
5. Reinstall the back cover in correct direction.
Please note that wrong mounting direction of the back cover will affect the circuit of
the module and may damage the module.
1
1 1
1
2
3
4
5
5
5
5
designated locations
