MSI MEG Unify-X Z690 - Jtpm1: Tpmモジュールコネクター; Jusb1~2: Usb 2.0コネクター

36
󴚮󸋖

󳲜󶬖
1
2 10
9
1 VCC 2 VCC
3  4 
5 USB0+ 6 USB1+
7 Ground 8 Ground
9 No Pin 10 NC

󴳇󳠴
 󳘗󳲜󶬖󴨟󳲜󶬖󲝉󲁹󴡇󲑟󳵊
󱫮
 󱱨󱯱󹩙
   

󳲜󶬖󸒏󶩆
󲀏󵒵󱚘
1
2 12
11
1 SPI Power 2 SPI Chip Select
3
Master In Slave Out (SPI Data) 4 Master Out Slave In (SPI Data)
5 Reserved 6 SPI Clock
7 Ground 8 SPI Reset
9 Reserved 10 No Pin
11 Reserved 12 Interrupt Request
