MSI MS7797 - Front Panel Connector; USB 3.0 Ports

1-19
7797
Chapter 1
F_PANEL1: Front Panel Connector
This connector connects to the front panel switches and LEDs. It is compliant with the
Intel
®
Front Panel I/O Connectivity Design Guide.
1.
+
3.
-
10.No
Pi
n
5.
-
Reset
S
witch
HDD
LE
D
P
ower
S
witch
P
ower
LE
D
7.
+
9.Reserve
d
8.
-
6.
+
4.
-
2.
+
Important
On the connectors coming from the case, pins marked by small triangles are positive
wires.
JUSB3: USB 3.0 Ports
USB 3.0 port is backward-compatible with USB 2.0 devices. Supports data transfer rate
up to 5 Gbit/s (SuperSpeed).
USB 3.0 connector
Important
If you want to use a USB 3.0 device, you must use the USB 3.0 cable to connect to the
USB 3.0 port.
