Chapter 1
Mainboard Speci󰘰cations
Processor Support
Support 3
rd
Generation Intel
®
Core™ i7/ Core™ i5/ Core™ i3/ Pentium
®
/ Celeron
®
Processors for LGA 1155 socket
Chipset
Intel
®
B75 chipset
Supports Intel
®
SBA
Memory Support
2x DDR3 DIMMs support DDR3 1600/ 1333/ 1066 DRAM (16GB Max.)
Supports Dual-Channel mode
LAN
Supports LAN 10/100/1000 Fast Ethernet by Realtek
®
RTL8111E
Audio
Integrated HD audio codec by Realtek
®
ALC887
6-channel audio with jack sensing
SATA
1x SATA 6Gb/s port (SATA1) by Intel
®
B75
3x SATA 3Gb/s ports (SATA2~4) by Intel
®
B75
USB 3.0
4x USB 3.0 ports by Intel
®
B75
Connectors
Back panel
1x PS/2 mouse port
1x PS/2 keyboard port
4x USB 2.0 ports
2x USB 3.0 ports
1x LAN port
1x HDMI port
1x VGA port
3x audio ports
On-Board
2x USB 2.0 connectors
2x USB 3.0 ports
1x Front Panel Audio connector
Slots
1x PCIe 3.0 x16 slot
2x PCIe 2.0 x1 slots
Form Factor
Micro-ATX (24.4 cm X 21.4 cm)
Mounting Screw Holes
6x mounting holes
■
■
-
■
■
■
■
■
■
■
■
■
-
-
-
-
-
-
-
-
■
-
-
-
■
■
■
■
