For M2_2 slot
1. If there is no EZ M.2 Clip installed, please install the supplied EZ M.2 Clip kit in the
M.2 slot according to your SSD length.
2. Insert your M.2 SSD into the M.2 slot at a 30-degree angle.
3. Rotate the EZ M.2 Clip to fix the M.2 SSD.
30º30º
11
22
33
6. Put the M.2 SHIELD FROZR heatsink back in place and secure it.
66
66
