MSI PRO Z690-P WIFI User Manual

19
󾖛󾖛󹴴󳩴󹩚󴽦󳲞󹲋
󹴴󳩴󹩚󴽦󳲞󹲋󲁗󱴹󵍤󷆄󲼏󸔩󸛚󴟜󳓑󲅈󴟜󳓑󾖜󴟜󳓑󹴴󳩴󳳨󲷔󳳣󱣼󳛟󲹥
󸱶󱴤󾖞󱚿󲁗󸸘󸺹󸹄󳐂󳲢󱵺󸏁󷵏󸔩󳿒󹴴󳩴󸹄󳐂󾖜
󴟜󳓑󳲞󷉥󲹥󶺳
󳲞󷉥 󸏁󷵏󲂁󶏺 󳲞󷉥 󸏁󷵏󲂁󶏺
1 Ground 2 +12V
3 Sense 4 Speed Control Signal
1
󴟜󳓑󳲞󷉥󲹥󶺳
󳲞󷉥 󸏁󷵏󲂁󶏺 󳲞󷉥 󸏁󷵏󲂁󶏺
1 Ground 2 Voltage Control
3 Sense 4 NC
󹴴󳩴󳲞󹲋󸋮󴑸
󳲞󹲋 󹱜󸐈󹴴󳩴󴟜󳓑 󴉷󲣴󹩚󴵍 󴉷󲣴󱸪󵢋
CPU_FAN1 󴟜󳓑 2A 24W
PUMP_FAN1 󴟜󳓑 3A 36W
SYS_FAN1~4 󴟜󳓑 1A 12W

󹆢󸋘
󳞅󲁗󱟧󲖬BIOS > HARDWARE MONITOR󱛉󸔩󳿒󹴴󳩴󸹄󳐂󾖜

MSI PRO Z690-P WIFI Specifications

General

Chipset	Intel Z690
Form Factor	ATX
Socket	LGA 1700
Memory Slots	4 x DIMM
Max Memory	128GB
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	1
PCIe 3.0 x1 slots	2
M.2 Slots	4
SATA Ports	6
USB 3.2 Gen 2x2 Ports	1
USB 3.2 Gen 2 Ports	3
Bluetooth	Bluetooth 5.2
Audio	Realtek ALC897
USB 2.0 Ports	6
Network	2.5G LAN
Wi-Fi	Wi-Fi 6
RAID Support	0, 1, 5, 10
