20
JCI1: Chassis Intrusion Connector
This connector allows you to connect the chassis intrusion switch cable.
JBAT1: Clear CMOS (Reset BIOS) Jumper
There is CMOS memory onboard that is external powered from a battery located on
the motherboard to save system configuration data. If you want to clear the system
configuration, set the jumpers to clear the CMOS memory.
Keep Data
(default)
Clear CMOS/
Reset BIOS
Resetting BIOS to default values
1. Power off the computer and unplug the power cord.
2. Use a jumper cap to short JBAT1 for about 5-10 seconds.
3. Remove the jumper cap from JBAT1.
4. Plug the power cord and Power on the computer.
Normal
(default)
Trigger the chassis
intrusion event
Using chassis intrusion detector
1. Connect the JCI1 connector to the chassis intrusion switch/ sensor on the chassis.
2. Close the chassis cover.
3. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
4. Set Chassis Intrusion to Enabled.
5. Press F10 to save and exit and then press the Enter key to select Yes.
6. Once the chassis cover is opened again, a warning message will be displayed on
screen when the computer is turned on.
Resetting the chassis intrusion warning
1. Go to BIOS > SETTINGS > Security > Chassis Intrusion Configuration.
2. Set Chassis Intrusion to Reset.
3. Press F10 to save and exit and then press the Enter key to select Yes.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the MSI PRO Z690-P WIFI and is the answer not in the manual?

MSI PRO Z690-P WIFI Specifications

General IconGeneral
ChipsetIntel Z690
Form FactorATX
SocketLGA 1700
Memory Slots4 x DIMM
Max Memory128GB
PCIe 5.0 x16 slots1
PCIe 3.0 x16 slots1
PCIe 3.0 x1 slots2
M.2 Slots4
SATA Ports6
USB 3.2 Gen 2x2 Ports1
USB 3.2 Gen 2 Ports3
BluetoothBluetooth 5.2
AudioRealtek ALC897
USB 2.0 Ports6
Network2.5G LAN
Wi-FiWi-Fi 6
RAID Support0, 1, 5, 10
