4
Specifications
CPU
Supports 12th Gen Intel® Core™ Processors
Processor socket LGA1700
* Please go to www.msi.com to get the newest support status as new processors
are released.
Chipset Intel® Z690 Chipset
Memory
4x DDR5 memory slots, support up to 192GB*
Supports 1R 4800 MHz (by JEDEC & POR)
• 1DPC 1R Max speed up to 6200+ MHz
• 1DPC 2R Max speed up to 5200+ MHz
• 2DPC 1R Max speed up to 4000+ MHz
• 2DPC 2R Max speed up to 4000+ MHz
Supports Intel® XMP 3.0 OC
Supports Dual Controller Dual-Channel mode
Supports non-ECC, un-buffered memory
* Please refer to www.msi.com for more information on compatible memory.
Expansion Slots
4x PCIe x16 slots
• PCI_E1 (From CPU)
• Support up to PCIe 5.0 x16
• PCI_E2 & PCI_E3 (From Z690 chipset)
• Support up to PCIe 3.0 x1
• PCI_E4 (From Z690 chipset)
• Support up to PCIe 3.0 x4
2x PCIe x1 slots
• PCI_E5 & PCI_E6 (From Z690 chipset)
• Support up to PCIe 3.0 x1
Multi-GPU Supports AMD CrossFire™ Technology
Onboard Graphics
1x HDMI™ 1.4 with HDR port, supporting a maximum
resolution of 4K 30Hz*/**
1x DisplayPort 1.4 port, supporting a maximum resolution
of 4K 60Hz*/**
* Available only on processors featuring integrated graphics.
** Graphics specifications may vary depending on the CPU installed.
SATA Ports 4x SATA 6Gb/s ports (From Z690 chipset)
Continued on next page
