MSI PRO Z690-P WIFI User Manual

5
Continued from previous page
M.2 SSD Slot
 2x M.2 slots (Key M)
• M2_1 slot (From CPU)
• Supports PCIe 4.0 x4
• Supports 2242/ 2260/ 2280/ 22110 storage devices
• M2_2 slot (From Z690 chipset)
• Supports PCIe 4.0 x4
• Supports SATA 6Gb/s
• Supports 2242/ 2260/ 2280 storage devices
• Supports Intel® Optane™ Memory
RAID
 Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA
storage devices
 Supports RAID 0, RAID 1 and RAID 5 for M.2 NVMe storage
devices
Audio
Realtek® ALC897 Codec
 7.1-Channel High Definition Audio
LAN  1x Realtek® RTL8125BG 2.5Gbps LAN controller
Wi-Fi & Bluetooth®
Intel® Wi-Fi 6
 The Wireless module is pre-installed in the M.2 (Key-E)
slot
 Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz (160MHz) up to
2.4Gbps
 Supports 802.11 a/ b/ g/ n/ ac/ ax
 Supports Bluetooth® 5.2
Power Connectors
 1x 24-pin ATX main power connector
 1x 8-pin ATX 12V power connector
 1x 4-pin ATX 12V power connector
Internal USB
Connectors
 2x USB 3.2 Gen 1 5Gbps connectors (From Z690 chipset)
• Supports additional 4 USB 3.2 Gen 1 5Gbps ports
 2x USB 2.0 connectors (From Z690 chipset)
• Supports additional 4 USB 2.0 ports
Continued on next page

MSI PRO Z690-P WIFI Specifications

General

Chipset	Intel Z690
Form Factor	ATX
Socket	LGA 1700
Memory Slots	4 x DIMM
Max Memory	128GB
PCIe 5.0 x16 slots	1
PCIe 3.0 x16 slots	1
PCIe 3.0 x1 slots	2
M.2 Slots	4
SATA Ports	6
USB 3.2 Gen 2x2 Ports	1
USB 3.2 Gen 2 Ports	3
Bluetooth	Bluetooth 5.2
Audio	Realtek ALC897
USB 2.0 Ports	6
Network	2.5G LAN
Wi-Fi	Wi-Fi 6
RAID Support	0, 1, 5, 10
