6
Continued from previous page
Fan Connectors
1x 4-pin CPU fan connector
1x 4-pin water-pump fan connector
4x 4-pin system fan connectors
System Connectors
1x Front panel audio connector
2x System panel connectors
1x Chassis Intrusion connector
1x TPM module connector
1x Tuning controller connector
1x TBT connector (Supports RTD3)
Jumpers 1x Clear CMOS jumper
LED Features
1x 4-pin RGB LED connector
1x 3-pin RAINBOW LED connector
4x EZ Debug LED
Back Panel
Connectors
1x PS/2 keyboard/ mouse combo port
2x USB 2.0 Type-A ports (From Z690 chipset)
1x DisplayPort
1x HDMI™ port
1x 2.5Gbps LAN (RJ45) port
4x USB 3.2 Gen 1 5Gbps Type-A ports (From Z690 chipset)
1x USB 3.2 Gen 2x2 20Gbps Type-C port (From Z690
chipset)
2x Wi-Fi Antenna connectors
6x audio jacks
I/O Controller NUVOTON NCT6687D-M Controller Chip
Hardware Monitor
CPU/ System/ Chipset temperature detection
CPU/ System/ Pump fan speed detection
CPU/ System/ Pump fan speed control
Form Factor
ATX Form Factor
12 in. x 9.6 in. (30.5 cm x 24.4 cm)
Continued on next page
