9. Tighten thrust screw (2) with torque wrench to the specified tightening torque.
Name Size Type Lubricant Value/Standard
Thrust screw Tightening torque 40 Nm ± 5 Nm
10. Install fuel line (3).
11. Tighten union nut on the injection pump to the specified tightening torque using a torque wrench.
Name Size Type Lubricant Value/Standard
Union nut Tightening torque 20 Nm + 5 Nm
12. Tighten union nut on the pressure pipe neck to the specified tightening torque using a torque wrench.
Name Size Type Lubricant Value/Standard
Union nut Tightening torque 20 Nm + 5 Nm
Final steps
1. Install cylinder head cover (→ Page 178).
2. Vent fuel system (→ Page 193).
MW15550/06E 2012-02 | Task Description | 185
TIM-ID: 0000004678 - 005
