MULTILIFT Ultima SL Flex - Diagnostic Codes

166
Ultima S / SL Flex & Pro
3/2019
114060421
Hooklift Multilift Ultima S / SL Flex & Pro
Service Manual
>>>
Diagnostic codes
ERROR CODE
COMMENTS / PROBLEM LOCATION
PROGRAM DESCRIPTION POSSIBLE ACTION CONSEQUENCE
FAULTS
-7F-
CAN BUS NOT ABLE TO COMMUNICATE WITH CONTROL BOX CAN LINKING
HARNESS
CAN BUS SIGNAL IS
MISSING
CHECK YELLOW AND GREEN WIRE BETWEEN CONTROL
UNIT AND 2024 MODULE
TOTAL STOP OF
SYSTEM
F000
SUPPLY VOLTAGE IS BELOW 16 VOLTS TRUCK
LOW POWER CHARGE TRUCK BATTERY TOTAL STOP OF
SYSTEM
F001
INTERNAL ERROR ON 2024 2024
INTERNAL ERROR 1 REPLACE 2024 IF ERROR REPEATS
F002
INTERNAL ERROR ON CONTROL BOX CONTROL BOX
INTERNAL ERROR 2 REPLACE CONTROL BOX IF ERROR REPEATS
F003
VALUES FROM PRESSURE SENSOR NOT LEGAL 2024
PRESSURE SENSOR CHECK CONNECTION / REPLACE SENSOR NO ACTION
F004
INTERNAL PARAMETER ERROR 2024
PARAMETER CHECK PARAMETERS / REPLACE MAIN BOX NO ACTION
F005
CAN BUS NOT ABLE TO COMMUNICATE WITH 2024 ANY POSITION
TIME OUT 1 CHECK BOX/CAN BUS WIRE & REPLACE IF NECESSARY NO ACTION
F006
CAN BUS NOT ABLE TO COMMUNICATE WITH CONTROL BOX ANY POSITION
TIME OUT 2 CHECK BOX/CAN BUS WIRE & REPLACE IF NECESSARY NO ACTION
F007
PROGRAM HAS STOPPED RUNNING 2024
NOT RUNNING POWER OFF/POWER ON TO RESET NO ACTION
F008
CAN BUS NOT ABLE TO COMMUNICATE WITH ANY BOX ANY POSITION
CAN BUFFER OVER RUN CHECK CAN BUS WIRE & REPLACE IF NECESSARY NO ACTION
F009
not used
