5. Open the container tail gate
- note the container operating instructions
- stand by the side of the container so that the opening tail gate and discharging
load do not hit you.
Open the mechanical or hydraulic front locks (optional).
6. If the truck is equipped with any of the following equipment, do the
following:
- retract the adjustable under-run bar (mechanical or manual hydraulic)
- press RETRACT UNDER-RUN BAR button
- the indicator light UNDER RUN BAR RETRACTED comes on in the control
unit
- deate the air suspension.
DO NOT USE THE BOGIE BLOCKING CYLINDERS OR
THE STABILISING ROLLER.
Under-run bar Bogie blocking cylinders Stabilising roller
Button LED comes on
