Hooklift Multilift Ultima S / SL Flex & Pro
User Manual
SECURE
7. Check that the container is locked
- hydraulic or mechanical locks are closed.
- the middle/rear frame (= tipping lock) must be closed
(See. ”Loading a short container”, paragraph 2)
- THE SIGNAL LIGHT OF THE CONTAINER LOCKING must not be lit.
8. Lift the main cylinders / middle frame together with the rear frame to the
desired or maximum tipping angle
- move the CONTROL LEVER slowly backwards (2GCC)
- press MAIN CYLINDERS BACK button (2GMR and 2GRC)
- the indicator light FRAME NOT DOWN comes on as the middle frame is rising
from the subframe
- the container must not touch the rear bumper of the truck or the ground.
Move the
control lever
back
Second LED
comes on
Button
