2 User Operating Instructions
2.1 Introduction
This section describes the operation of the Multitone RPR 750 Series radio-paging
receiver, including the location and function of each button and indicator. Unless
otherwise stated, operation is common to all variants in the Series.
Note should be made of all the warnings and cautions outlined in the Preliminary Section
and Section 1 of this manual, especially in relation to use of this equipment in hazardous
areas.
2.2 Controls & Indicators
See Figure 2.1 below for the controls, indicators and User access points, associated with
the RPR 750 Series.
Figure: 2.1 User Access and Control Points
LANYARD RETAINER
BATTERY
COMPARTMENT DOOR
CHARGING &
PROGRAMMING CONTACTS
GRIPTITE CLIP
MUTE
BUTTON
LED CALL INDICATOR
ON/CANCEL/RECALL
(OCR) BUTTON
ALPHA-NUMERIC
LC DISPLAY
