Page10of33
IMC08 Banknote Counter & Sorter User Manual
Version 1.03
6) Use only power cords provided by MUNBYN.
7) Do not use the machine outdoors.
8) Do not expose the machine to liquids.
9) This machine contains moving parts and sharp edges. Always be careful. Do not touch the components
inside the machine while it is running. Keep jewelry, long hair, ties, and lanyards away from the
machine at all times.
10) Please be careful to avoid any foreign objects, such as coins or staples, falling into the unit, as it may
cause damage to the machine.
3.2.2. Power Supply Connection
Figure 3-1 Power and External Display Connection
3.2.3. Banknote Guide Installation
Figure 3-2 Banknote Guider Installation
