IMC08 Banknote Counter & Sorter User Manual
Version 1.03
7.0. Software Update
You may need to upgrade the machine. To do this, use a USB flash drive to upgrade this product. Please
upgrade the software using the following steps.
1) The upgrade file needs to be moved to the root directory of the USB flash drive. (please do not change
the file name or format of the upgrade file, and there cannot be two or more upgrade files in the root
directory of the USB flash drive)
2) Turn the power off to the machine. Insert the USB flash drive into the USB interface at the rear of the
machine.
Figure 7-1 USB Upgrade Port
3) Turn on the IMC08, and the machine will automatically recognize the upgrade file. Upon successful
recognition, the machine will read the file first.
Figure 7-2 Upgrade File Reading
4) Next it will program the file into the machine.
Figure 7-3 Program the Upgrade File
