IceDry800/1400
requirementsfortheequipmentinordertoachievethebestpossibleperformanceandfacilitateservicing.
Therefore,complywiththerecommendedservicespaces,seesection8.1,Dimensionsandservicespace.
NOTE!Theunitmustberemovedfromthecoldstoreatcertainserviceintervals.Haveextracablesforunit
connectionavailable.
4.4Mirrorhandedductconnections
Thefrontandbackpanelsareinterchangeable,sothattheconnectionsforprocessanddryairmaybe
situatedeitherontheleftorrightsideoftheunit.
Thedehumidiersaredeliveredwiththeprocessanddryairconnectionsontheleftsideoftheunit.Ifitis
requiredtothechangetheorientation,sothattheconnectionsareontherightsideoftheunit,proceed
asfollows.
W W
W
ARNING! ARNING!
ARNING!
Ensurethatmainpowerisisolatedfromthedehumidierpriortochangingtheorientatinoftheprocessanddryair
connections.
B
A
C
D
E
F
1.Removethetwobolts(B)securingthefrontpanelandcarefullyremovethepanel.
2.Removethetwoboltssecuringtherearpanelandcarefullyremovethepanel.
3.Removethetwobolts(A)andwasherssecuringthecontrolandtoppanels,thencarefullyremovethe
toppanel.
4.Removethecableductcovers(C),re-routethecablesandtthecontrolpanel(D)ontotheoppositeside
oftheunit.Retthecableductcovers.
5.Loosentherotorstop(E)andthetwoltermonitors(F).Removethecableties.
6.Fittherotorstopandltermonitorsontheoppositesideoftheunit.Tiethecables.
7.Fitthefront,rearandtoppanelsintheirnewpositions.
190TGB-1037-G1307Installation7
