Munters ICEDRY 800 - Sound Data

IceDry800/1400
External(Volt-free)OutputContacts
2
2A,50VAC2A,50VAC
MaxnoiselevelUnducted(dBA)8080
1
Figuresquotedarenominal,basedonfaninlettemperatureof20°C,andanairdensityof1.2kg/m
3
.
2
ContactsonthePCBusedtogivearemotefaultoutput
Table8.1Technicalspecications
8.3Sounddata
CorrectionKokdBatISO-bandcentrefrequency,Hz
Noisefor
dB(A)Lwt631252505001000200040008000
Duct1Na101-10-2-9-13-20-22-27-33
Duct2Na102-3-5-13-20-20-19-21-26
Duct3Na94-5-6-5-1720-21-23-27
Duct4Na88-2-6-12-25-31-31-33-35
Room6490-1-8-14-16-20-23-26-31
Noisepathstosurroundings
1.Ductworkfordryair
2.Ductworkforprocessair
3.Ductworkforreactivationair
4.Ductworkforwetair
SYMBOLS
Lwt=TotalnoiseleveldB(rel.10-12W)
Lw=NoisepowerlevelinoctavebanddB(rel.10-12W)
Kok=CorrectionforcalculatingLw(Lw=Lwt+Kok)
dB(A)=Ratednoiselevelat100m
2
roomabsorption
28Technicalspecication190TGB-1037-G1307
