4.11Airowcheckandadjustment
ContactMuntersServicefordehumidierinstallationandadjustment.TheaddressestoMunterscanbe
foundonthebackpageofthismanual.
CA CA
CA
UTION! UTION!
UTION!
Iftheprocessandreactivationairowsarenotproperlyadjusted,theunitcanmalfunction.Theairowmustbeset
tomaximum10%abovethespeciednominalvaluelistedinsection8.2,Technicaldata.
1.Byadjustingthedampersinstalledinthedryairoutletandreactivationairinletducts,theprocessand
reactivationairowscanbechangedtotherequiredsetting.
2.Startthedehumidierforapproximately10minutestoallowthereactivationheatertoreachitsnormal
operatingtemperature.Seesection5.5,Operatingtheunit.
3.Checkthatthetemperaturedifferencebetweenreactivationairdownstreamoftheheater,andthe
regenerationtemperatureisapprox.95°C(tolerancelimitis±5°C).
4.Ifthetemperaturedifferenceliesoutsideofthetolerancelimit,thereactivationairdampercanbe
adjustedinsmallsteps(whichcausesthetemperatureindicatortostabiliseaftereachadjustment)until
reactivationtemperatureiswithinthespeciedtolerances.
Example:
Inletairtemperature=15°C
Reactivationairtemperature=110°C
Temperatureincrease=95°C
