Munters ICEDRY 800 - Ductwork for Wet Air Outlet

IceDry800/1400
4.6.5Ductworkforwetairoutlet
Thewetairductmustbemadeofplasticoranothercorrosionresistantmaterial.Itmustbeabletohandle
temperaturesbetween-30°Cand75°C,benomorethan1.5metreslongandbeinsulatedtopreventice
formation.Thisalsoappliestothepartoftheductpassingthroughthewall.
Becauseofitshighmoisturecontentthewetairleavingthedehumidierwillcondenseontheinsideof
theductwalls.Duetothelowambienttemperaturethereisariskoficeformation.Thewetairductmust
thereforebeinsulated.
■Horizontalductsmustbeinstalledwithaslightdecline(awayfromthedehumidier)todrainaway
possiblecondensation.Thedeclinemustbeatleast2cm/mofduct.
■5mmdrainholesshouldbemadeatlowpointsoftheducttopreventwateraccumulationintheduct.
■Topreventtheoutgoingwetairfromhumidifyingtheincomingreactivationair,thewetairoutletmust
beplacedatleast2metresfromthereactivationinlet.SeeFigure4.1.
NOTE!Alwaysdrillthedrainholesontheoutsideofthecoldstorage/freezerroomwall.
W W
W
ARNING! ARNING!
ARNING!
Thewetairoutletishot.Toavoidburnsfromunintendedcontact,makesureitisinsulated.
10Installation190TGB-1037-G1307
