Recovery firmware -
system startup
Tab. 9-16: Extended LED display, recovery firmware - system startup
Recovery firmware -
system initialization
Tab. 9-17: Extended LED display, recovery firmware - system initialization
Recovery firmware:
system run
Tab. 9-18: Extended LED display, recovery firmware - system run
LED Display State Description
ST
Yel low
Flash, flash,
pause
(double flash)
Recovery firmware: system startup
BUS_RUN
CfgF
POWER UA
POWER US
Off
LED Display State Description
BUS RUN
Green
Lights continu-
ously
Recovery firmware: system initializa-
tion
ST
Yel low
Flash, flash,
pause
(double flash)
CfgF
Yellow
Flashing at 1
Hz
POWER UA
POWER US
Off
LED Display State Description
BUS RUN
CfgF
Green
Lights continu-
ously
Recovery firmware: system run
ST
Yel low
Flash, flash,
pause
(double flash)
POWER UA
Yellow
Flashing at 1
Hz
POWER US
Off
