Technical Data
User manual 55530_hdb_en_16 36 / 156
4.3 Art.-No. 55532 MVK-MPNIO DIO12 IOL4 IRT
4.3.1 Electrical data
Bus data
Fieldbus protocol PROFINET
FSU (fast start-up) ≤500 ms
Shared device/input For 2 controllers Yes
Specification V2.3, Conformance
Class C (IRT)
PROFINET Netload Class III
Transfer rate 100 Mbit/s
PROFINET addressing Via DCP
Cycle time ≥1 ms
IRT (isochronous real time) Network communication Yes
Application No
MRP (media redundancy) Client Yes
PROFIenergy V1.2
Supply
Operating voltage US 24 V
Voltage range US 18 ... 30 V
When using IO-Link 20.3 ... 30 V
Operating voltage UA 24 V
Voltage range UA 18 ... 30 V
Max. sensor current US 9 A
Max. actuator current UA 9 A
Current consumption In idle state ≤0.18 A
Cross-section of 7/8" connector ≤1.5 mm
2
Reverse polarity protection for US and UA Yes
Reverse polarity protection Yes
Galvanic isolation None
Input
Filter time 1 ms
Processing time for signal change 2 ... 5 ms
Input characteristic EN 61131-2, type 3
Sensor power supply port DIO ≤0.2 A load
Automatic start
Sensor power supply IO-Link port ≤1 A load
Automatic start
Short circuit protection High-side switch with
overload protection
Connection M12
Conductor cross-section M12 ≤0.75 mm
2
Output
DIO port output current ≤1.6 A per channel
IO-Link port output current From HW 2.0 ≤1.6 A per channel
Switching frequency ≤50 Hz
