Operation
User manual 55530_hdb_en_16 140 / 156
9.3.1 General diagnostic messages
Tab. 9-21: General diagnostic messages - error types, meaning and action
9.3.2 General diagnostic messages at IO-Link ports
Tab. 9-22: Diagnostic messages at IO-Link ports - error types, meaning and action
Channel
Error Type
Extended Channel
Error Type
Meaning Action
0x9 0x4000 Unknown error
0x01 0x4101 Sensor short circuit Check the wiring to the female connector in question.
0x01 0x4117 Actuator warning Check the wiring to the female connector in question.
0x01 0x4118 Actuator short circuit Check the wiring to the female connector in question.
0x02 0x4228 Actuator undervoltage Check the actuator supply voltage of the module.
0x11 0x4229 No actuator power supply Check the actuator supply voltage of the module.
0x02 0x4232 Sensor undervoltage Check the sensor supply voltage of the module.
0x11 0x4233 No sensor supply Check the sensor supply voltage of the module.
0x03 0x432C Actuator overvoltage Check the actuator supply voltage of the module.
0x03 0x4334 Sensor overvoltage Check the sensor supply voltage of the module.
0x17 0x57F9 Internal communication error Please contact Murrelektronik.
Channel
Error Type
Extended Channel
Error Type
Meaning Action
0x10 (16) 0x50E0 (20704) IODD-on-board: Error in
GSDML
Please contact Murrelektronik.
0x10 (16) 0x50E0 (20704) IODD-on-board: General er-
ror
Please contact Murrelektronik.
0x10 (16) 0x50E1 (20705) IODD-on-board: Error in
GSDML
Please contact Murrelektronik.
0x10 (16) 0x50E2 (20706) IODD-on-board: Error in
GSDML
Please contact Murrelektronik.
0x10 (16) 0x50E3 (20707) IODD-on-board: Error in
GSDML
Please contact Murrelektronik.
0x10 (16) 0x50E4 (20708) IODD-on-board: Error in
GSDML
Please contact Murrelektronik.
0x10 (16) 0x50E5 (20709) IODD-on-board: Invalid pa-
rameter value
Check the parameterization on the module.
0x10 (16) 0x50E6 (20710) IODD-on-board: Invalid pa-
rameter value
Check the parameterization on the module.
0x10 (16) 0x50E7 (20711) IODD-on-board: Invalid pa-
rameter value
Check the parameterization on the module.
