Mounting

User manual 55530_hdb_en_16 42 / 156

5.3 Mounting distance

Fig. 5-2: Distance in mm

NOTICE

 For correct installation and improved heat dissipation, we recommend

keeping a minimum distance of 3 mm when mounting the MVK-MPNIO.

NOTE

 When using angled connectors, a minimum distance of 50 mm to the wall,

ceiling and between the modules must be kept.
