Installation

User manual 55530_hdb_en_16 49 / 156

6.1.1 Sensors and actuators

Connecting the

M12 ports

Fig. 6-1: Example of M12 connection inputs and outputs

NOTE

Feeding in an external mass via M12 female connectors can lead to faults.

 Do not feed external mass to the module via M12 female connectors.

You will find a wide range of connecting wires in the catalog or in the online

shop of Murrelektronik GmbH at: http://shop.murrelektronik.com

M12 0,6 Nm

Art.-No.

7000-99102-0000000
