Appendix VJ-2638/1638/1638W OPERATION MANUAL
294 8.1 Product specifications
8.1 Product specifications
8.1.1 Printer specifications
Items Specification
Model name VJ-1638W VJ-1638 VJ-2638
Printing method On-demand piezo drive system
Drive system Firmware servo/DC motor drive
Media feed system Multipoint pressurizing grid roller system
Media fixing system Pressurization roller down system by manual lever
Media feed/ejection Rear feed/Front ejection
Roll media outer diameter 150mm or less 250mm or less
Roll media weight 30kg or less 100kg or less
Maximum media width 1,625 mm 2,642 mm
Minimum media width 900 mm
Maximum media thickness 0.3 mm (when the head height is Low)/1.3 mm (when the head height is Mid)/
2.8 mm (when the head height is High)
Maximum printable media width 1,615 mm 2,632 mm
Print margin Top: 5 mm (15 mm after media initialization or after winding the media
manually, 40 mm when media initialization front edge detection is ON or after
cutting the media), Bottom: 5 mm (102 mm at the roll media end), Left: 5 mm
to 25 mm, Right: 5 mm to 25 mm.
Media cut system Horizontal automatic cut system/manual cut system
Head height adjustment Three-level adjustment of Low, Mid, and High
CPU 64-bit RISC CPU
Memory 256 MB 384MB
Command MH-RTL (RTL-PASS)
Interface Ethernet (10BASE-T/100BASE-TX) Ethernet (10/100/
1000BASE-T)
Ink Supply system Supplied through tubes from independent color cartridges
Cartridges Black, Cyan, Magenta,
Yellow: 220ml ± 5ml each
Black, Cyan, Magenta, Yellow: 220ml ± 5ml
each or 440ml ± 5ml (1000ml ± 5ml when the
optional High-capacity ink pack adapter is used)
