VJ-2638/1638/1638W OPERATION MANUAL Before using
3.3 Filling ink 45
3.3.4 Installing High Capacity Ink Pack Adapter (option) for VJ-
2638/1638
Use the optional High-capacity ink pack adapter to use the 1000ml Ink packs on VJ-2638/1638.
NOTE
High-capacity ink pack adapters are not compatible with VJ-1638W.
Follow the procedure below to install High-capacity ink pack adapter.
1. 1.Check the angle of Ink cartridge slot to see if the insertion angle of Ink cartridge is horizontal.
• If the insertion angle of Ink cartridge is not horizontal, change the angle.
3.3.3 Changing the angle of Ink cartridge slot
2. Turn the printer ON.
• The printer starts the initializing operation.
• •After the initial operation is compete, "Start Ink Charge – > E" is displayed on Operation panel.
No. Name
1 Ink cartridge slot
1
1
