ValueCut KullanımKılavuzu
Installation 2-5
Adım 6
Insert the roll holder support with the screws into the holes of the stand, and then tighten them
up as shown in Şekil 2-7. You could decide roll holder support’s position by inserting into
different holes.
Adım 7
Place two roll holders into the holes in the roll holder support. (Şekil 2-8)
Roll holder support
Roll holders
Roll holder
support
3 screws
Şekil 2-7
Şekil 2- 8
