ValueCut Kullanım Kılavuzu
Trouble Shooting 7-7
7.5 Cutting Quality Problems
Is the blade installed correctly and the blade
holder fastened securely?
Y e s
No
Is the blade dull
or chipped?
Y e s No
Replace
blade
Is tool force set up
properly? (The default
for tool force is 80 gf)
Y e s
No
Adjust the tool force to obtain an
optimum blade force. Refer to
Chapter 4.3 “Cutting Force and
Offset Adjustment”
Is the tool offset set up
properly?
Y e s
No
Adjust the tool offset to
obtain an optimum value.
Is there any dirt adhered to
the blade?
Y e s
No
Refer to Chapter 2.4
“ Blade Installation”
Remove the blade
and clean it.
Please contact your dealer for technician
support.
Note: The daily maintenance of your cutting plotter is very important. Be sure to clean up the
grid drum and pinch rollers regularly for better cutting accuracy and output quality.
To Next Page
