Trouble Shooting 7-5
7.3 Cutting Plotter/Computer Communication Problems
The messages showed below present problems in relation to cutting plotter/computer
communication.
Communication Error
Setup: MISC. key
Is the connection cable
connected to the cutting plotter
and computer properly?
Y e s No
Has the interface setting
been done correctly?
Refer to Chapter 2 -
Connecting your cutting
plotter.
Y e s No
Try the communication
between your cutting plotter
and computer. If it still does
not work, have your cutting
plotter serviced.
Refer to the “MISC” key in
Chapter 3 - Description of
Operation for the port setup.
If your cutting plotter can not recognize
the HP-GL/2 or HP-
GL commands, please
check the HP-GL/2 or HP-
GL commands
applied to your cutting plotter are
used
properly.
Note:
The computer also needs to set up compatible communication parameters to the cutting
plotter set up.
HP-GL/2 Cmd. Error
