MUTOH VC-600 - Page 22

ValueCut KullanımKılavuzu
Installation 2-10
Adım 3
Insert the basket rods to the basket holes (See Şekil 13)
Adım 4
Loosen the basket screws from the basket arms. Position the basket rod in front of the basket
arms and insert the basket screws into the holes on the basket rod and tighten them. (Şekil
14)
Basket rods
Basket
Şekil 2-13
Şekil 2-14
Basket screw
Basket rod
Basket arm
