ValueCut Kullanım Kılavuzu
Operation
4-5
Adım 4
Turn the roll downward to make an equal tension across the media (Şekil 4-11)
Adım 5
Move the pinch rollers to the appraise location and
note that the pinch rollers must be positioned above
the grid drums.
Adım 6
Push the lever backward to lower down the pinch rollers.
Adım 7
Fix roll media guide bushes on the roll holder to secure the roll media.
Adım 8
Turn on the power switch, the tool carriage will sizing the media automatically.
Then the cutting plotter is ready to work.
Adım 9
Use the reverse steps to remove the media.
Şekil 4-11
Şekil 4-10
Note:
Make sure that the media tension is equally distributed from left to right. If the media were not
tightened enough against the platen, it would cause tracking problems!
