MUTOH VC-600 - Page 7

ValueCut Kullanım Kılavuzu
Table of Contents
5. Automatic Aligning System
5.1 Introduction 5-1
5.2 Calibrating the System 5-2
5.2.1 Media Calibration 5-2
5.2.2 AAS Calibration 5-2
5.2.3 AAS II on ValueCut 5-3
5.2.4 Automatic Distinction of the Plot Direction 5-5
5.3 Printer Test 5-5
5.4 Registration Mark Offset Range
5.5 Contour Cutting
5-7
5-7
5.6 Tips for AAS 5-9
6. Maintenance
6.1 Cleaning the cutting Plotter 6-1
6.2 Cleaning the Grid Drum 6-2
6.3 Cleaning the Pinch Rollers 6-2
7. Trouble Shooting
7.1 Non-Operational Problems 7-1
7.2 Operational Problems 7-2
7.2.1 LCM Error Messages 7-2
7.2.2 Other operational problems 7-3
7.3 Cutting Plotter/Computer Communication Problems
7-5
7.4 Software Problems 7-6
7.5 Cutting Quality Problems 7-7
Appendix
A-1 ValueCut Specification A-1
A-2 Blade Specification A-2
A-3 Consumable and Optional Item List A-3
A-4 CorelDRAW Plug-In Instruction A-4
A-5 Illustrator Instruction A-5
