ADJUSTMENTS 5
5
EN
The light beam can be adjusted vertically by turn-
ing the screw illustrated. If turned in a clockwise
direction: the optical unit tilts upwards. If turned in
an anti-clockwise direction: the optical unit tilts
downwards. It can be tilted up to an angle of ±4°
from the standard position.
Clockwise
Counterclockwise
