TECHNICAL INFORMATION 8
8
EN
- 202 -
Description F3 675
Dry weight 179 Kg - 394.6 lbs
Fuel tank capacity (*) 16 lt (4.22 U.S. gal)
Reserve fuel (*) 5 lt (1.32 U.S. gal)
Oil in crankcase 2.5 lt (0.66 U.S. gal)
ENGINE
Type Three-cylinder, four-stroke, 12 valves
Bore 79 mm (3.1 in)
Stroke 45.9 mm (1.8 in)
Total displacement 675 cm
3
(41.19 cu.in)
Compression ratio 13 : 1
Starting Electric starter
Cooling system Cooling with separate liquid and oil radiators
Crankcase and covers Die-cast
Head and cylinders Chill-cast
Valves Titanium
VALVE TRAIN
Type Double-overhead camshaft
Specifications
* : The indicated data must not be intended as binding informations. They can change according to the environmental tempe-
rature, the engine temperature and the evaporation point of the gasoline.
