Suspension and wheels
F
- 21 -
Manually turn the counternut in to the end of the
threaded portion.
The counternut is characterized by a special
fitting direction. Ensure that the two span-
ner resting surfaces are facing up (see fol-
lowing figure).
Fit in the spring.
Fit the spanner to damping piston nut (1), pressing
down slightly on the spring.
Position spring pressing spacer (1) with the related
washer.
Reassemble the complete cap with a new O-ring.
