Suspension and wheels
F
- 81 -
Tighten the 5 nuts to block the silentblocks as shown
in the figure.
Tightening torque: 25 N·m
Do not apply grease
Reposition the nut of the flange (1) with the relative
washer (2) without tightening.
Using the special spanner, bring the eccentric back
into position by rotating in an anti-clockwise direction to
tighten the chain.
Special tool:
Spanner for eccentric hub N. 800092854
Extension for spanner N. 800092855
Whenever the chain is tightened, it is neces-
sary to adjust the stability of the vehicle -
see "Adjusting vehicle stability" in this
chapter.
25 N•m
2
1
