Suspension and wheels
F
- 83 -
Remove the screw (1) of the clutch control cylinder and
the three screws (2) of the pinion wheel cover.
Remove the cover being careful to not extract the clut-
ch control rod (it must remain inserted in the engine)
and be careful to not lose the two centralising bushes
indicated in the figure.
Straighten the metal tongue with a flat-head drift and
hammer.
Unscrew the pinion wheel retaining nut.
Now cut and remove the chain as described on pages
58÷62.
1
2
