Suspension and wheels
F
- 86 -
2
Using an Allen key, change the centre distance
between the two half linkages by turning adjuster (3).
Repeat these operations until X
1
is equal to the refer-
ence dimension.
3
Manually and firmly tighten the two tightening lock nuts
of the half supports until you hit the adjuster bar.
Press down the saddle to compress the rear shock
absorber, then allow the vehicle to spring back to its
rest position.
