PRODUCT MANUAL iCOOK - DT.MP.IC.2201.2
In the case of a new installation, the water must be left to run until the
connection is completely purified. This operation must be repeated each
time work or repairs are carried out on the water system that feeds the oven.
5.2.2. Drain
For the correct operation of the steam system of the iCOOK ovens, the equipment must be
connected to a drainage system with a nominal diameter of 40mm (DN40) through a heat-
resistant, siphon-type pipe.
The Mychef iCOOK oven incorporates an internal system to block any odors that may come
from the drain.
Figure 4. Drainage
For correct operation, bear in mind that the pipe must have a constant slope of at least 5º.
The drain must be a maximum of 1 meter long, have a diameter greater than
the drain connection and be free of bottlenecks.
