PRODUCT MANUAL iCOOK - DT.MP.IC.2201.2
8.1.2. Stainless steel exterior surfaces
Use only a soft cloth with a little soapy water to clean the stainless-steel exterior surfaces.
Rinse and dry carefully.
Do not clean the exterior of the equipment after use, wait until the surfaces
are at room temperature.
8.1.3. Fan and heat exchanger zone
The part that separates the cooking chamber with the fan and heat exchanger can be
removed to clean this area. In order to remove the protector, it is necessary to unscrew the
two lower screws that hold the protection to the bottom of the chamber (A), once these
screws are free, lift the protection and extract it to the outside (B).
Only use a soft cloth with a little soapy water to clean the interior surfaces. Rinse and dry
carefully.
Before removing the fan protector, the tray guides must be removed.
Figure 54. Fixing system of the fan and exchanger protector
