• For instructions on making electrical connections, see the attached diagram.
The wires must have a minimum cross section size of 1.5 mm².
• Install a 4 A (ampere) fast safety fuse on the + wire of the battery. Do not use
the voltage generated by the engine battery set to provide power.
• The instrument complies with EMC standards (EN55022) and must be
positioned at a distance of:
− 30 cm (~1 Ft) from the compass;
− 50 cm (~1.5 Ft) from radio equipment;
− 2 metres (~6.5 Ft) from radio transmitter equipment;
− 2 metres (~6.5 Ft) from the radar beam.
