GT 710-8710 Swing Door System Low Energy Operator www.NabcoEntrances.com
Part #15-10683 Rev. 9-24-14
1-4 Scope
CHAPTER 1: SCOPE
Secon 1a: To the Installer
The purpose of this manual is to familiarize the installer and purchaser with the proper
installation and operation of this system. It is essential that this equipment be properly installed
and operational before the door is used by the public. It is the installer’s responsibility to inspect
the operation of the entrance system to be sure it complies with any applicable standards. In the
United States, ANSI Standard 156.19; ANSI Standard 117.1 and the Low Energy Operator section
of ADA Standard covers the GT 710/8710 Swing Door Low Energy System. Other local standards
or codes may apply. Use them in addition to the ANSI standard. Low Energy Swing door Units are
Instruct the building owners and operator on the essentials of the operation of the Swing door.
The owner should follow these instructions to determine whether the door is operating properly
and should immediately call for service if there is any malfunction. All installation changes and
If after troubleshooting a problem, a satisfactory solution cannot be achieved, please call Nabco
Entrances at 1-877-622-2694 between 8 am – 4:30 pm Central time for additional assistance.
• Turn OFF all power to the Automatic Door if a Safety System is not working.
• Instruct the Owner to keep all power turned OFF until corrective action can be
achieved by a NABCO trained technician. Failure to follow these practices may
result in serious consequences.
• NEVER leave a Door operating without all Safety detection systems operational.
Secon 1b: Objecve
GT 710/8710 Swing Door Low Energy Units are designed to be installed onto the top surface of
the Door Frame. The Operator is controlled by the Magnum IV Control that offers many features to
accommodate most installation options. This manual offers step by step instructions.
