www.NabcoEntrances.com GT1175StandardandPocketedSlideDoorsInstallaonManual;withOpusController
Rev.11-12-20 P/NC-00370

Glass
DN 1033
Gap
Aluminum Hood
Mark Line
Vinyl Shield
Surface
Adhere Vinyl Shield
along Mark Line
Tuck Aluminum Hood
under Vinyl Shield
Adhere Aluminum
Hood to Glass Stop
Aluminum Hood
Inside Face
Cladding Tape
Cladding Tape
Assembly
Vinyl Shield
Vinyl Flap
Figure 70 

Note: All Aluminum Hoods and Vinyl Shields are installed for Clean Room Slide Door Units only and are not manufactured by
NABCO. Please call Customer Service for replacement parts at 1-888-679-3319.
Note: Aluminum Hoods are installed at the boom of each Door panel and Transom.
1. Install the Glass Stops. Place each Aluminum Hood over each Glass Stop so the boom edge of the Aluminum Hood is
resng on the surface.
a. Do Not remove protecve paper from double sided Cladding Tape at this me.
2. Insert the boom half of each Vinyl Strip inside the gap that is located behind the Aluminum Hood. The Vinyl Flap must be
laying on top the Aluminum Hood.
3. Hold the assembly in place while it is pressed up against the Glass Panel. Make a temporary Mark along the full length of the
Vinyl Strip. Ensure the boom edge of the Aluminum Hood is sll resng on the surface for proper alignment.
4. Remove the assembly and the protecve paper to expose the Cladding Tape from the Vinyl Shield.
5. Align the Vinyl Strip to the temporary Mark and adhere to the Glass Panel.
6. Remove the protecve paper to expose the Cladding Tape from the Aluminum Hood.
1. Align the Aluminum Hood with the Vinyl Shield.
2. Adhere the Aluminum Hood to the Glass Stop and tuck it under the Vinyl Flap.

1. Install the Glass Stops. Go to the (Removable Cover) side of Header.
2. Posion the Stainless Steel Hood on top of the Header so the (turned under) boom lip is resng on the Header surface and
the inside face is pressed up against the building. Ensure proper length and t is correct.
3. Remove all protecve paper to expose the Cladding tape. Adhere the Stainless Steel Hood to the Header.
DN 1034
Building
Dust Protector Hood
Header
45
3/8”
1/2”
Figure 71 
