6 of 62
GT1175 Standard and Pocketed Slide Doors Installaon Manual; with Opus Controller www.NabcoEntrances.com
P/N C-00370 Rev 11-12-20
X
•
•
Feature GT1175 / Opus v27 GT1175 / U30
Operator VS-150 High Voltage Brushless Motor DC-150 Low Voltage Brushless Motor
Fully Programmable Open, Close, Check Speeds Yes Yes
Bluetooth Compable Yes No
Number of Auxiliary Outputs 3 (1 x Relay and 2 Transistors) 2 (1 x Relay and 2 Transistors)
Relay Output Rang 3A at 110VAC 3.2A (20 to 30V) 42V Peak
Transistor Output Rang 100mA 47 mA
Number of Programmable Inputs 3 inputs 1 input
Programmable door Handing Yes Yes
Requires Handy Terminal No Yes
12VDC available on Control Board 12VDC; 750mA 12VDC; 350mA
Compable with all acvang devices such as
Wall Switches, Card Readers, Keypads, etc.
Yes Yes
On board Programming Yes No
Opening speed (based on 500 pound door) Aer 1 second - 29 inches/second Aer 1 sec - 18 inches/second
DN 2261
①
②
③
④
⑤
⑥
⑦
⑧
1 VS 150 Operator V-00914 5 Timing Belt 3/4” wide V-00917
2 Power Cut O Switch N/A 6 Idler Assembly A-01419
3 Opus Control Assembly A-01418 7 An Rise Roller A-00163
4 Belt Clip Assembly See Header Service Parts Page 8 Hanger Roller A-00162
1. Ensure the Rough Opening is correct size.
X PACKAGE WIDTH + 1/4 INCH ON EACH SIDE
X PACKAGE HEIGHT + 1/4 INCH
Note: Make allowances for le or other exisng materials that may change the oor height.
2. Ensure the oor is level across the enre opening. If used, check recessed threshold across the door opening.
