www.NabcoEntrances.com GT1175StandardandPocketedSlideDoorsInstallaonManual;withOpusController
Rev.11-12-20 P/NC-00370
1 M-00606 BUSHING, BOTTOM PIVOT, SWING PANEL 2 Protect inside of Barrel from dust/dirt.
2 T-00008 FHSMS,1/4x2.750L.,PHIL,TAPCON,BLUE 2 Secure Boom Pivot (M-00611) to oor
3 T-00007 FHMS,1/4-20x0.500L.,PHIL,UNDRCUT,F-PT,ZN 2 Secure Boom Pivot (M-00611) to oor.
2 Secure Boom Pivot (M-00611) to Pivot Jamb Tube.
2 Secure Clip (M-01174) to oor.
4 T-00222 Zinc PHSMS,6x0.500L.,PHIL,TEKS,ZINC 12 Secure Brush Holder to Door Panels.
T-00260 Black Zinc PHSMS,6x0.500L. PHIL,TEKS BLK ZN
5 M-00611 FLOOR PIVOT BRACKET 2 Allow Sidelite to swing Open and Closed
6 A-00060 Narrow LIMIT ARM,SWING PANEL,ASM.NRW.STILE 1 Allow Sidelite to swing Open and Closed
7 T-00069 WASHER,.255 ID,.900 OD,.125 THK,NYLON 1 Keep Screw from digging into face of Limit Arm
8 T-00083 FHMS,1/4-20x1.000L.,PHIL,UCUT,VIBRATITE 1 Secure Limit Arm to boom of Header
9 T-00010 HHCS,1/4-20x0.750L.,WHIZLOCK,ZINC 2 Secure Belt Bracket to Carrier on top of Slide Door
12 Secure Header to Jamb Tubes
10 T-00009 PHSMS,6x0.375L,PHIL,TYPE AB,18-8 SS 3 Secure Threshold End Cap to the Threshold
11 M-00442 END CAP 1 Keep Bumper material in place.
12 T-00261 SHSS,5/16-24x0.500L.,CUP PT. 1 Adjust PreLoad (top of Strike Sle on Slide Door)
13 M-01174 CLIP,BASE,MULLION 1 Keep the Full Open Sidelite closed.
14 T-00083 FHMS,1/4-20x1.000L.,PHIL,UCUT,VIBRATITE 1 Secure Clip (M-01174) to Strike Sle.
Full Open Pocketed
