NAD 375BEE C Service Manual

CONTENTS
FRONT PANEL/REAR PANEL VIEW3
SPECIFICATIONS4
ALIGNMENT PROCEDURE/ALIGNMENT POINTS
5-7
WIRING DIAGRAM8
S
CHEMATIC DIAGRAM

9-18
PCB LAYOUT19-
27
ELEC
TRICAL PARTS LIST

28-48
EXPLODED VIEW49
EXPLOD
ED
VIEW PARTS LIST

50
PACKING DIAGRAM51
VERSION HISTORY. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
SERVICE SAFETY PRECAUTIONS
1. Replacing the Fuses
CAUTION: FOR CONTINUED PROTECTION AGAINST THE RISK OF FIRE
REPLACE ONLY WITH SAME TYPE OF FUSE.
REFERENCE NO. PART NUMBER DESCRIPTION
Rear Panel
AH A20-12103-00 Littelfuse618 T10AL/250V
C A20-12702-20 Littelfuse618 T5AL/250V
STANDBY Board
F401 A20-12102-00 Littelfuse618 T1AL/250V
NOTE:
*AH : North American version only
*C : European version only
2. Safety-check out (North American model only)
Before returning the product to the customer, make leakage current or
resistance measurements to determine that exposed parts are acceptably
insulated from the supply circuit.
Parts marked with the symbol are critical with regard to the risk of fire and
electric shock.Replace only parts recommended by the manufacturer.
- 2 -

NAD 375BEE C Specifications

General

Signal-to-Noise Ratio	>100dB (A-weighted)
Input Impedance	20k Ohms
Inputs	7 x Line Level, 1 x Phono
Outputs	Preamp out
Power Output	150W x 2 (8 Ohms)
Damping Factor	>150 (8 Ohms)
