NAD 375BEE C Service Manual

PREAMPLIFIERS SECTION
THD(2V in 2V out,CCIF IMD,DIM 100) < 0.004 %
Signal/Noise IHF re 500mV output A wtd. > 102 dB
S/N re 2V output, max volume > 110 dB
S/N re 100mV o/p (unity gain) > 92 dB
Channel separation 1KHz > 80 dB
10KHz > 70 dB
Input impedance 100kohms+320pF
Max input, 0.1% thd > 8 V rms
Output impedance pre out 75 ohms
Output impedance variable out < 325 ohms
Output impedance tape out source Z + 1k ohms
Input sensitivity for 500mV out 158 mV
Frequency response 20-20k tone defeat on < +/- 0.1dB
tone defeat off < +/- 0.5 dB
Max output ( 0.03% thd) IHF load > 10 V
Max output 600 ohm,s load > 10V
Tone controls Bass at 100Hz +/- 8 dB
Treble at 10KHz +/- 5dB
POWER AMPLIFIERS SECTION
Continuous average power , stereo,8 and 4 ohms at rated thd ,20-20k > 150W
Continuous average power 8 ohms , bridge mode > 330W
Rated thd, 20-20k, SMPTE and CCIF IMD, DIM 100 < 0.009%
Clipping power ( 1% thd at 1kHz) >170W
IHF dynamic power 8 ohms >250W
IHF dynamic power 4 ohms >410W
IHF dynamic power 2 ohms >600W
IHF dynamic power 8 ohms(Bridge Mode) >800W
IHF dynamic power 4 ohms(Bridge Mode) >1200W
Peak output current 1msec, 1 ohm > 50A
S/N A wtd re 1 W >102 dB
S/N A Wtd re 150W >123 dB
Damping factor ( re 8 ohms, 50 Hz and 1kHz) > 200
Frequency response 20-20k < +/- 0.1 dB
Frequency response - 3dB 3Hz – 70 kHz
Input impedance 10kohms+200pF
Input sensitivity for rated power 1.2 V
Voltage gain 29dB
Headphone output impedance 270 ohms
Channel separation. 1kHz > 85 dB
10kHz > 75 dB
Trigger out
Output resistance < 120 ohms
Output current 50mA
Output voltage +12V
OVERALL CD In Speaker Out
THD 20-20k, CCIF IMD, DIM 100 , 0.25W to rated power < 0.009%
S/N A wtd re 1 W > 94dB
S/N A wtd re 150W ( volume set for 2V input) > 113 dB
Frequency response 20-20k Tone defeat in < +/- 0.2 dB
Frequency response -3dB 10 - 65kHz
Channel separation 1KHz > 80 dB
10KHz > 70 dB
Rated power ( 230 or 120 V AC 50.60 Hz) 290 W
Standby power <1W
Idle power <120W
Net weight 15.3 kg
Shipping weight 18 kg
Dimensions 435x133x352 mm
- 4 -
SPECIFICATIONS

NAD 375BEE C Specifications

General

Signal-to-Noise Ratio	>100dB (A-weighted)
Input Impedance	20k Ohms
Inputs	7 x Line Level, 1 x Phono
Outputs	Preamp out
Power Output	150W x 2 (8 Ohms)
Damping Factor	>150 (8 Ohms)
