NAD 375BEE C - C375 BEE;C275 BEE Opamp Board - Component Side; C375 BEE;C275 BEE Opamp Board - Solder Side

C375BEE/C275BEE Opamp BOARD - SOLDER SIDE
Q610
C375BEE/C275BEE Opamp BOARD - COMPONENT SIDE
Q609
VP1.0 Oct.10.2008
31
Q611
P601A
C375BEE/C275BEE Opamp
Q612
- 24 -
PCB LAYOUT (Only replace Line In or Line Out modules, do not repair)
Line in module C611 is 39pF M201 01-37506-10
Line out module C611 is 47pF M301 01-37506-20
